Nordberg GP cone crushers have been developed to crush feed materials into desired end products efficiently, reliably, and economically. Metso's Mining and Construction, the global leader in rock crushing technology, has developed the Nordberg GP cone crusher series to fulfill all crushing needs. Incorporating the latest crusher know-how, the Nordberg GP Series combines the highest crushing efficiency and end product quality with the lowest per ton production costs. Nordberg GP series crushers embody the 100+ years of commitment to first-class crusher design and product development at Metso. As a result, the GP Series offers several outstanding features that enable you to work efficiently in any secondary, tertiary or quaternary crushing applications. If your aggregate or mining business demands big capacities, first-class cubicity or full mobility, you will find a Nordberg GP crusher optimized for your needs. The GP Series crushers also provide you with unlimited possibilities in smooth process adaptation and full crushing process automation. All of this is backed by our worldwide, comprehensive pre- and aftersales support services. Take a closer look at the Nordberg GP Series crushers. You will be sure to find a GP cone crusher ideally suited to your needs.
We can supply following parts for GP series cone crusher.
We have 20 years of experience to make these parts. Our parts can provide the best performance and the longest service life. Due to scale effect. The price is also very cheap. This will keep your machine running steadily with low cost.
Crusher Type | Parts Name | Parts No | Crusher Type | Parts Name | Parts No |
G11FINE | Head | 949617139100 | GP200 | Cooling fan | N02154524 |
G11FINE | Mantle | 814317169500 | GP200 | Head nut | 932867 |
G11MFINE | Mantle | 814318848600 | GP200 | Protection plate | 908862 |
G11MFINE | Mantle | 814320044100 | GP200 | Spacer ring | 933335 |
G11FINE | Concave | 814317169600(171696) | GP200S | Concave | 814390727800 |
G11FINE | Concave | 814317171900 | GP200 | Mantle | N11933947 |
G11FINE | Concave | 814317177700 | GP200F | Concave | N11944214 |
G11MFINE | Concave | 814318675800 | GP200S | Mantle | 814390727700 |
G11MFINE | Concave | 814318848700 | GP200S | Concave, Upper | 814390727900 |
GP11F | Mantle check nut | 285342 | GP200S | Concave lower | 814391704400 |
GP200S | Concave, Upper | 814391704500 | |||
Crusher Type | Parts Name | Parts No | GP200 | Head cover | MM0514397 |
G12 | Bearing | 315932 | GP200S | Main nut | 908674 |
G12 | Thrust Bearing | 315933 | GP200 | Main Shaft Sleeve | 908632 |
G12 | Bushing | 292722 | GP200 | Dust Seal Retainer | 915449 |
GP250 | Top bearing | MM0539639 | |||
Crusher Type | Parts Name | Parts No | GP250 | Setting piston | MM0537894 |
GP11 | MANTLE | 814317169500 | GP200/S | Bearing | MM0531018 |
GP11 | MANTLE | 814320044100 | GP250 | Hub | MM0539142 |
GP11 | Concave | 814328546000(285460) | GP250 | Slip ring | MM0538053 |
GP11 | Mantle chack nut | 285342 | GP200/GP200S | Thrust plate | 927769 |
GP11 | Pressure plate | 949647119100(471191) | GP250 | Eccentric shaft | MM0537743 |
GP11 | Thrust bearing | 949626155700(261557) | GP200/GP200S | Bevel gear ~ Pinion gear | 908083/908085 |
GP11 | Curve | 312446 | GP200 | Thrust bearing | 927855 |
GP11 | Ring,seal | 949630438400 | GP200 | Eccentric bushing | 933617 |
GP11 | Ring,seal | 949640515600 | GP220 | Bearing | MM0538260 |
GP11 | Gear ~ pinion set | MM0218088 | GP200 | Frame bushing | 908655 |
GP11 | Frame bushing | 949620310900 | |||
GP11 | Thrust bearing | 949620310100(203101) | Crusher Type | Parts Name | Parts No |
GP11 | Protection bushing | 312150 | GP300 | Mantle | N11933947 |
GP300 | Concave | N11944214 | |||
Crusher Type | Parts Name | Parts No | GP300 | Mantle | 814390727700 |
GP100 | Mantle | 814328537800(814328537800) | GP300 | Concave, Upper | 814390727900 |
GP100 | Mantle | 814390490400 | GP300 | Mantle | 814318940300 |
GP100 | Mantle | MM0309236 | GP300 | Concave | 814390455800 |
GP100 | Concave | 814317178300(814317178300) | GP300 | Mantle | N11920192(N11920192) |
GP100 | Concave | 814317183600 | GP300 | Mantle | N11920196 |
GP100 | Concave | 814318865500 | GP300 | Concave | N11905094 |
GP100 | Concave | 814328537700 | GP300 | Concave | N11920194 |
GP100 | Concave | 814329529300 | GP300 | Concave | N11920195(N11920195) |
GP100S | Mantle | 814317177900 | GP300 | Concave | N11920197 |
GP100S | Concave | 814328546200 | GP300 | Concave, Upper | 814318862100 |
GP100S | Concave, Upper | 814328546300(285463) | GP300 | Concave, Upper | 814329276200 |
GP100S | Concave | 814328570600 | GP300 | Concave | 814318862000 |
GP100S | Concave, Upper | 814329234600 | GP300 | CONCAVE,LOWER | 814329276100(292761) |
GP100S | Cover | MM0243918 | GP300 | Thrust Bearing | 446193 |
GP100S | Bearing Bushing | 949617145500 | GP300 | Top Bearing E25/32/40/50 | 295251 |
GP100S | Bearing Bushing | 949617145600 | GP300S | Mantle | 814318836900 |
GP100 | Frame bushing | 949628506200 | GP300S | Mantle | 814390336100 |
GP100 | Cylinder bushing | 946558 | GP300S | Concave | 814390336200 |
GP100 | Seal | 406302285800 | GP300S | Eccentric Bushing 18/25/32/40 | 188325 |
GP100 | Main nut | 285176 | GP300S | Nut TR300X12-8H | 292721 |
GP100 | Seal | 949638681800 | GP300 | Spacer ring | 446421 |
GP100 | Torch ring | 949641828500 | GP300 | Concave EC | MM0242241 |
GP100 | O-ring | N02701369 | GP300 | Mantle C/EC | MM0242240 |
GP100 | Dust seal ring | 418460 | GP300 | Frame Bushing | 931714 |
GP100 | Bearing | 418481 | GP300 | Bearing E25/32/40 | 189276 |
GP100 | Protection bushing | 418274 | GP300 | Thrust bearing | 315933 |
GP300 | Pressure plate | 949644619300 | |||
Crusher Type | Parts Name | Parts No | GP300 | Thrust bearing | 315932 |
GP500 | Mantle | 814318607800 | GP300 | Bushing | 341336 |
GP500S | Mantle, Thin | N11941326 | |||
GP500 | Concave | 814318921300 | Crusher Type | Parts Name | Parts No |
GP500 | Concave | 814390523400 | GP550 | Filter element | 02445792 |
GP500 | Nut | 287906 | GP550 | Mantle | N11951717 |
GP500 | Torch Ring | 495349 | GP550 | Mantle | N11951712 |
GP500S | Mantle | 814329548400 | GP550 | Concave | N11951714 |
GP500S | Concave | 814390882100 | |||
GP500S | Concave, Upper | 814390882200 | |||
GP500S | Concave, Upper | N11947963(N11947963) | |||
GP500S | Concave | N11941328 |
We focus on providing high quality crusher and crusher wear spare parts.
Symons cone crusher 2 feet, 3 feet, 4.25 feet, 5.5 feet, 7 feet.
Sandvik CH420, CH430, CH440, CH660, CH880, CS420, CS430, CS440, CS660.
HP100, HP200, HP300, HP400, HP500, HP700, HP800.
And wear spare parts for other common crushers.
